Name	AIM-132 ASRAAM (Advanced Short-Range Air-to-Air Missile)
Country of origin	United Kingdom (MBDA)
Type	Short range air-to-air missile
Varients	ASRAAM P3I ASRAAM Block-6 (No USA made component)
Range	25 km
Max altitude	Not known
Length	2.90 m
Diameter	166 mm
Fin span	450 mm
Mass	88 kg
Flight Duration	Not known
Warhead	10 kg blast/fragmentation
Detonation Mechanism	Laser proximity fuze and impact
Warhead yield	Not known
Max Speed	Mach 3
Propulsion	Dual-burn, high-impulse solid rocket motor
Engine	Solid rocket motor
Guidance	infrared homing, 128×128 element focal plane array, with lock-on after launch (LOAL) and strapdown inertial guidance
Launch platform	Eurofighter Typhoon Lockheed Martin F-35 Lightning II McDonnell Douglas F/A-18 Hornet SEPECAT Jaguar
Service period	1998-Present
Description	The AIM-132 ASRAAM (Advanced Short-Range Air-to-Air Missile) is a high-speed, highly maneuverable, imaging infrared homing air-to-air missile designed for close-range combat. Developed by MBDA UK, it is intended for “fire-and-forget” engagements, allowing the launching aircraft to break away after firing. ASRAAM features exceptional maneuverability and a powerful imaging infrared seeker, enabling it to effectively engage highly agile targets in challenging combat scenarios. It is currently in service with the Royal Air Force and other air forces worldwide.
Website	https://www.mbda-systems.com/

Disclaimer: This information is based on publicly available sources and should be considered for general knowledge purposes only.
